ASUS Pro WS TRX50-SAGE WIFI AMD TRX50 Socket sTR5 SSI CEB
ASUS Pro WS TRX50-SAGE WIFI AMD TRX50 Socket sTR5 SSI CEB
SKU: 90MB1FZ0-M0EAY0
Regular price
$929.99 USD
Regular price
Sale price
$929.99 USD
MSRP: $929.99
ASUS Pro WS TRX50-SAGE WIFI. Processor manufacturer: AMD, Processor socket: Socket sTR5, Compatible processor series: AMD Ryzen Threadripper 1000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 1 TB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. USB connector type: USB Type-A, USB Type-C. Ethernet interface type: 2.5 Gigabit Ethernet, 10 Gigabit Ethernet, LAN controller: Intel I226-LM, Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Quantity
Couldn't load pickup availability
- Details: ASUS Pro WS TRX50-SAGE WIFI. Processor manufacturer: AMD, Processor socket: Socket sTR5, Compatible processor series: AMD Ryzen Threadripper 1000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 1 TB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. USB connector type: USB Type-A, USB Type-C. Ethernet interface type: 2.5 Gigabit Ethernet, 10 Gigabit Ethernet, LAN controller: Intel I226-LM, Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Info: AMD sTR5 socket supports up to 96-core CPUs: Ready for AMD Ryzen™ Threadripper™ PRO 7000 WX-Series Processors and AMD Ryzen Threadripper 7000 Series Processors|CPU and memory overclocking: Support for up to 1TB ECC R-DIMM DDR5 memory modules (1DPC)|Robust power and thermal design: 36 power stages with two 8-pin power connectors for the CPU, massive VRM cooling, chipset and M.2 heatsinks, and M.2 thermal pad|Ultrafast connectivity: three PCIe® 5.0 x16 slots, 10 Gb & 2.5 Gb LAN ports, three M.2 slots, front and rear USB 20Gbps Type-C® and SlimSAS NVMe support|Server-grade IPMI remote management: hardware and software support for ASUS IPMI expansion cards, plus ASUS Control Center Express software for real-time monitoring and management|Trusted stability: Validated for extensive compatibility with the latest technologies, an expansive QVL list, and tested for 24/7 operation
- Clear CMOS button: Yes
- BIOS type: UEFI AMI
- BIOS memory size: 256 Mbit
- Component for: Workstation
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 4.x) slots: 2
- PCI Express x16 (Gen 5.x) slots: 3
- Product color: Black
- Motherboard form factor: SSI CEB
- Motherboard chipset family: AMD
- Audio chip: Realtek ALC1220P
- On-board graphics card: No
- USB 2.0 connectors: 2
- ATX Power connector (24-pin): Yes
- Chassis intrusion connector: Yes
- Number of chassis fan connectors: 4
- Number of COM connectors: 1
- TPM connector: Yes
- CPU fan connector: Yes
- EPS power connector (8-pin): Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Front panel audio connector: Yes
- 12V power connector: Yes
- USB 3.2 Gen 2x2 connectors: 1
- Integrated SAS ports: 1
- Maximum internal memory: 1 TB
- Memory channels: Quad-channel
- Supported memory types: DDR5-SDRAM
- ECC ?ompatibility: ECC
- Memory slots type: DIMM
- Number of memory slots: 4
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet, 10 Gigabit Ethernet
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Wi-Fi standards: Wi-Fi 7 (802.11be)
- Bluetooth: Yes
- Bluetooth version: 5.4
- LAN controller: Intel I226-LM
- Cables included: PCIe, SATA
- Package width: 12.6" (320 mm)
- Package height: 3.94" (100 mm)
- Package depth: 15" (380 mm)
- Package weight: 10.7 lbs (4.85 kg)
- USB connector type: USB Type-A, USB Type-C
- Motherboard chipset: AMD TRX50
- Compatible processor series: AMD Ryzen Threadripper 1000 Series
- Ethernet LAN (RJ-45) ports: 2
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 6
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- Microphone in: Yes
- S/PDIF out port: Yes
- Number of SATA III connectors: 4
- Processor manufacturer: AMD
- Processor socket: Socket sTR5
- WiFi-AP antenna jack: 1
- Number of storage drives supported: 7
- RAID levels: 0, 1, 5, 10
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
- Number of HDDs supported: 4
- Windows operating systems supported: Windows 10 x64, Windows 11
- Weight: 5.58 lbs (2.53 kg)
- Width: 12" (305 mm)
- Depth: 11" (280 mm)
