ATEN AT-VS482
ATEN AT-VS482
SKU: VS482
Regular price
$245.59 USD
Regular price
Sale price
$245.59 USD
MSRP: $311.00
ATEN AT-VS482. Video port type: HDMI, Video in: 4 x HDMI Type A Female (Black), Video out: 2 x HDMI Type A Female (Black). Material: Metal, Product color: Black, Maximum operating distance: 590.6" (15 m). Width: 17.2" (437.2 mm), Depth: 6.24" (158.6 mm), Height: 1.73" (44 mm)
Quantity
Couldn't load pickup availability
- Details: ATEN AT-VS482. Video port type: HDMI, Video in: 4 x HDMI Type A Female (Black), Video out: 2 x HDMI Type A Female (Black). Material: Metal, Product color: Black, Maximum operating distance: 590.6" (15 m). Width: 17.2" (437.2 mm), Depth: 6.24" (158.6 mm), Height: 1.73" (44 mm)
- PDF: http://objects.icecat.biz/objects/mmo_29406582_1509369760_8087_14281.pdf|http://objects.icecat.biz/objects/mmo_29406582_1509369791_4589_27349.pdf
- Info: Allows up to four HDMI A/V sources to be connected to two HDMI displays|HDCP 1.4 compatible, HDMI (3D, Audio Return Channel and Deep Color)|Supports Dolby True HD and DTS HD Master Audio|Audio Return Channel (ARC) function – connect an HDMI cable to the ARC port to send audio from your source device to your audio/video receiver|OSD for system configuration setting and information display|Instant switching between HDMI input sources via front panel pushbuttons or through the RS-232 serial control port|Feature EDID Expert technology to set up different configurations via different EDID mode|Allows users to view the HDMI input source port / device for easy selection|Supports superior video quality – HDTV resolutions of 480p, 720p, 1080i, 1080p (1920x1080); up to WUXGA (1920 x 1200)|Built-in bi-directional RS-232 serial control port for high-end system control *|Extra audio from HDMI input signal that supports both optical and coaxial digital audio and one stereo audio output|IR control signal extension – extend the reach of the IR controller by adding an IR receiver unit|Rack mountable|* Note: The VS482 AP and GUI operation instructions can be downloaded from the ATEN website (www.aten.com)
- Rack mounting: Yes
- HD type: Full HD
- Supported graphics resolutions: 1920 x 1080 (HD 1080)
- 3D: Yes
- Supported video modes: 1080p
- Product color: Black
- Bandwidth: 225 MHz
- Maximum operating distance: 590.6" (15 m)
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Width (imperial): 17.21"
- Depth (imperial): 6.24"
- Height (imperial): 1.73"
- User guide: Yes
- Handheld remote control: Yes
- Video port type: HDMI
- Maximum resolution: 1920 x 1080 pixels
- DC-in jack: Yes
- HDMI ports quantity: 6
- HDCP: Yes
- RS-232 ports: 1
- Audio (L/R) out: 2
- Number of HDMI outputs: 2
- Video in: 4 x HDMI Type A Female (Black)
- Video out: 2 x HDMI Type A Female (Black)
- HDMI in: 4
- Compliance certificates: RoHS
- Material: Metal
- Weight: 4.78 lbs (2.17 kg)
- Width: 17.2" (437.2 mm)
- Height: 1.73" (44 mm)
- Depth: 6.24" (158.6 mm)
