ATEN CE700A console extender
ATEN CE700A console extender
SKU: CE700A
Regular price
$243.58 USD
Regular price
Sale price
$243.58 USD
MSRP: $323.00
ATEN CE700A. Cables included: KVM, USB
Quantity
Couldn't load pickup availability
- Details: ATEN CE700A. Cables included: KVM, USB
- PDF: http://objects.icecat.biz/objects/4017858_407.pdf
- Info: Cat 5e cable connects the Local and Remote Units - up to 150m apart|Dual console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles|Built-in ASIC for greater reliability and compatibility|Auto Signal Compensation (ASC)|USB Keyboard and USB Mouse Ports|USB overcurrent detection and prevention|Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes.|Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection|Automatic gain control - adjusts signal strength to compensate for distance|High resolution video - up to 1920 x 1200@60Hz (30m ); 1600 x 1200@60Hz (100m); 1280 x 1024@60Hz (150m)|Supports Wide Screen formats *|Supports VGA, SVGA, SXGA, UXGA, WUXGA and multisyncmonitors; local monitor supports DDC; DDC2; DDC2B|Rack mountableEasy to install - no software required - connecting cables to the devices is all it takes|Multiplatform support - Windows, Linux|* The EDID data for a widescreen is sent from the local video output port. For widescreen modes and displays connect the monitor to the local video output port or use an ATEN EDID emulator.
- Product color: Black
- Harmonized System (HS) code: 84733020
- Mounting kit: Yes
- Cables included: KVM, USB
- Maximum transfer distance: 5905.5" (150 m)
- USB 2.0 ports quantity: 2
- VGA (D-Sub) ports quantity: 2
