ATEN CE750A KVM extender Transmitter & receiver

ATEN CE750A KVM extender Transmitter & receiver

CE750A

$412.08 USD
$412.08 USD
Sale Sold out

MSRP: $556.00

ATEN CE750A. Type: Transmitter & receiver, Connectivity technology: Wired, Maximum transfer distance: 7874" (200 m). Transmitter local video port type: VGA, Transmitter local keyboard/mouse port type: USB. Receiver local video port type: VGA, Receiver local keyboard/mouse port type: USB. Transmitter width: 3.4" (8.63 cm), Transmitter depth: 7.95" (20.2 cm), Transmitter height: 0.984" (2.5 cm)
View full details
    • Details: ATEN CE750A. Type: Transmitter & receiver, Connectivity technology: Wired, Maximum transfer distance: 7874" (200 m). Transmitter local video port type: VGA, Transmitter local keyboard/mouse port type: USB. Receiver local video port type: VGA, Receiver local keyboard/mouse port type: USB. Transmitter width: 3.4" (8.63 cm), Transmitter depth: 7.95" (20.2 cm), Transmitter height: 0.984" (2.5 cm)
    • Info: Local and Remote units connect at distances up to 200 meters using Cat 5e cable|Dual console operation – control your system from both the local and remote USB keyboard, monitor, and mouse consoles|Built-in ASIC for greater reliability and compatibility|USB keyboard and USB mouse ports|RS-232 serial ports – allows you to connect to a serial terminal for configuration (Local Unit) or serial devices such as touchscreens and barcode scanners (Remote Unit)|Supports stereo speakers and stereo microphone|USB overcurrent detection and prevention|Pushbutton operating mode selection (Local Unit only) – select between Local and Auto operating modes|Built-in 8KV/15KV ESD protection (contact voltage 8KV, air voltage 15KV) and 2KV surge protection|Adjustable gain control – automatically and manually adjusts signal strength to compensate for distance|High resolution video – up to 1920x1200@60Hz at 30m,1600x1200@60Hz at 150m, 1280x1024@60Hz at 200m|Supports VGA, SVGA, SXGA (1280 x 1024), UXGA (1600 x 1200), and multisync monitors; local monitor supports DDC, DDC2, DDC2B|Hot pluggable|Rack mountable|Easy to install – no software required, simply connect cables to the devices|Supports wide screen formats*|* The EDID data for a widescreen is sent from the local video output port. For widescreen modes and displays, connect the monitor to the local video output port or use an ATEN EDID emulator.
    • Certification: RoHS
    • Product color: Black
    • Type: Transmitter & receiver
    • KVM port selection: Push-buttons
    • Cable types supported: Cat5
    • Operating temperature (T-T): 0 - 50 °C
    • Storage temperature (T-T): -20 - 60 °C
    • Operating relative humidity (H-H): 0 - 80%
    • Connectivity technology: Wired
    • Maximum transfer distance: 7874" (200 m)
    • Maximum digital resolution: 1920 x 1200 pixels
    • Receiver local keyboard/mouse port type: USB
    • Receiver local video port type: VGA
    • Material: Metal
    • Transmitter local video port type: VGA
    • Transmitter local keyboard/mouse port type: USB
    • Transmitter width: 3.4" (8.63 cm)
    • Transmitter depth: 7.95" (20.2 cm)
    • Transmitter height: 0.984" (2.5 cm)
    • Transmitter weight: 16.6 oz (470 g)
    • Receiver weight: 16.6 oz (470 g)
    • Receiver width: 3.35" (8.51 cm)
    • Receiver depth: 7.95" (20.2 cm)
    • Receiver height: 0.984" (2.5 cm)
