ATEN CL3884NW KVM switch Rack mounting Black
ATEN CL3884NW KVM switch Rack mounting Black
SKU: CL3884NW
Regular price
$3,467.82 USD
Regular price
Sale price
$3,467.82 USD
MSRP: $3,740.00
ATEN CL3884NW. Keyboard port type: USB, Mouse port type: USB, Console ports: HDMI, USB A. Maximum resolution: 1920 x 1080 pixels, Video bandwidth: 60 Hz, Scan interval: 5,10,15,30,60,90 s. Product color: Black, Housing material: Metal, LED indicators: Power. Display: LED, Display diagonal: 18.5". Input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz, Input current: 1 A
Quantity
Couldn't load pickup availability
- Details: ATEN CL3884NW. Keyboard port type: USB, Mouse port type: USB, Console ports: HDMI, USB A. Maximum resolution: 1920 x 1080 pixels, Video bandwidth: 60 Hz, Scan interval: 5,10,15,30,60,90 s. Product color: Black, Housing material: Metal, LED indicators: Power. Display: LED, Display diagonal: 18.5". Input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz, Input current: 1 A
- PDF: http://objects.icecat.biz/objects/mmo_79325412_1600684495_7511_24557.pdf
- Info: Reliability and Operational Versatility|Multi-view console controls up to four video sources on one screen with display modes including Quad View, Picture in Picture (PiP), Picture by Picture (PbP), and Picture on Picture (PoP)|Quick Access Toolbar – intuitive user interface for editing|Supports an extra console via USB/HDMI connectors for up to two console displays*|Display mode layout customization|Superior video quality – 1920 x 1200 @ 60 Hz|Computer selection via pushbuttons, hotkeys, OSD, and RS-232 commands|Boundless Switching – simply moves the mouse cursor across windows to switch to other video sources|Video DynaSync™ – an exclusive ATEN technology that eliminates boot-up display problems and optimizes the resolution when switching among different sources|Easily resizes and/or repositions any PiP or PbP to suit users’ viewing needs|EDID Expert™ – selects optimum EDID settings for smooth power- up, high-quality display and use of the best video resolution across different screens|Cascade up to 2 levels – controls up to 16 computers (with up to 4 x 4 Multi-View mode)|Auto Scan mode – enables continuous monitoring of user-selected computers|Broadcast mode – allows users to send commands from the console to all computers to perform operations simultaneously|Additional hot-pluggable USB peripheral port on front panel|*Both outputs can provide a combination of multi-view display modes simultaneously. However, users can only have one of the two outputs set to full-screen mode.|Space Utility Optimization|Exclusive LED illumination light – designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions|Integrated KVM console with an 18.5” LED-backlit widescreen LCD monitor in a dual rail housing with top and bottom clearance for smooth operation in a 1U high system rack|Dual rail design allows LCD monitor and keyboard/touchpad modules to operate independently|Console lock – enables the console drawer to remain securely locked away in position when not in use|Installation Flexibility|Standard rack mount kit included|Optional rack mount kits available, including easy installation options*|No software required|Firmware upgradable|Supports hot-plugging|*Contact your ATEN dealer for product information.
- LED indicators: Power
- Rack mounting: Yes
- Display: LED
- Push button: Yes
- Display diagonal: 18.5"
- Product color: Black
- Housing material: Metal
- Hot keys: Yes
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 85%
- Built-in display: Yes
- USB connector type: USB Type-A
- Keyboard port type: USB
- Mouse port type: USB
- Maximum resolution: 1920 x 1080 pixels
- Video bandwidth: 60 Hz
- Scan interval: 5,10,15,30,60,90 s
- Serial ports quantity: 1
- HDMI ports quantity: 5
- Number of computers controlled: 4
- USB 2.0 Type-B ports quantity: 4
- Audio connections: Yes
- Console ports: HDMI, USB A
- Console USB ports quantity: 2
- Serial port type: RJ-45
- AC input frequency: 50 - 60 Hz
- Input voltage: 100 - 240 V
- Input current: 1 A
- Compliance certificates: RoHS
- Weight: 24.7 lbs (11.2 kg)
- Width: 24.8" (631 mm)
- Height: 1.69" (42.8 mm)
- Depth: 18.9" (480 mm)
