ATEN CS1708A KVM switch Rack mounting Black
ATEN CS1708A KVM switch Rack mounting Black
SKU: CS1708A
Regular price
$487.62 USD
Regular price
Sale price
$487.62 USD
MSRP: $643.00
ATEN CS1708A. Keyboard port type: USB, PS/2, Mouse port type: USB, PS/2, Video port type: VGA. Maximum resolution: 2048 x 1536 pixels, Scan interval: 1,255 s. Product color: Black, Rack capacity: 1U, Housing material: Metal. Power source: DC, Input voltage: 5.3 V, Power consumption (typical): 5 W. Compliance certificates: RoHS
Quantity
Couldn't load pickup availability
- Details: ATEN CS1708A. Keyboard port type: USB, PS/2, Mouse port type: USB, PS/2, Video port type: VGA. Maximum resolution: 2048 x 1536 pixels, Scan interval: 1,255 s. Product color: Black, Rack capacity: 1U, Housing material: Metal. Power source: DC, Input voltage: 5.3 V, Power consumption (typical): 5 W. Compliance certificates: RoHS
- PDF: http://objects.icecat.biz/objects/mmo_30341381_1509365370_6793_2572.pdf
- Info: One USB-PS/2 console controls up to 8 computers|Daisy-chain up to 31 additional units - control up to 256 computers from a single console|Front accessible USB port allows each computer to access USB peripherals *|Dual Interface - supports computers and console with PS/2 or USB keyboards and mice|Multiplatform support - Windows, Linux, Mac and Sun|Video DynaSync™ - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution|Supports USB keyboards for PC, Mac and Sun|Auto PS/2 and USB interface detection|USB / PS/2 keyboard and mouse emulation - computers boot even when the console focus is elsewhere|Superior video quality - up to 2048 x 1536; DDC2B|No software required - convenient computer selection via front panel pushbuttons, hotkeys and multilingual on-screen display (OSD) menus|Auto-senses station's position on daisy-chained installations; no need for manual dip switch setting; front panel led indicates station's position|Port names automatically reconfigured when station sequence is changed|Two level password security; only authorized users view and control computers; up to four users and an administrator with separate profiles for each|Auto Scan feature for monitoring user-selected computers|Broadcast Mode - operation simultaneously performed on all selected computers... etc|Hot pluggable - add or remove computers without having to power down the switch|Buzzer on/off via hotkey and OSD|Firmware upgrades to all the chained KVM switch at the same time via the daisy-chain cable|Rack mountable in 19" system rack (1U)|* The USB peripheral function only works with USB cable set connections. It will not work with PS/2 cable set connections.
- LED indicators: Yes
- Rack mounting: Yes
- Push button: Yes
- On Screen Display (OSD): Yes
- Product color: Black
- Housing material: Metal
- Daisy chain: Yes
- Hot keys: Yes
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Hot-Plug support: Yes
- Cables included: KVM
- Firmware upgradeable: Yes
- Built-in display: No
- USB connector type: USB Type-A
- Keyboard port type: USB, PS/2
- Mouse port type: USB, PS/2
- Video port type: VGA
- Maximum resolution: 2048 x 1536 pixels
- Scan interval: 1,255 s
- DDC2B support: Yes
- DC-in jack: Yes
- Number of computers controlled: 256
- Console ports: USB A, VGA (D-Sub)
- Console USB ports quantity: 1
- Power consumption (typical): 5 W
- Input voltage: 5.3 V
- Power source: DC
- Mac operating systems supported: Yes
- Windows operating systems supported: Yes
- Linux operating systems supported: Yes
- Other operating systems supported: Yes
- Compliance certificates: RoHS
- Rack capacity: 1U
- Weight: 5.86 lbs (2.66 kg)
- Width: 17.2" (437.2 mm)
- Height: 1.73" (44 mm)
- Depth: 6.3" (159.9 mm)
