• ATEN CS1762A KVM switch Black
  • ATEN CS1762A KVM switch Black
  • ATEN CS1762A KVM switch Black
1 3

ATEN CS1762A KVM switch Black

ATEN CS1762A KVM switch Black

CS1762A

$198.54 USD
$198.54 USD
Sale Sold out

MSRP: $259.00

ATEN CS1762A. Keyboard port type: USB, Mouse port type: USB, Video port type: DVI-I. HD type: WUXGA, Maximum resolution: 1920 x 1200 pixels, Scan interval: 1,99 s. Product color: Black, Housing material: Metal. Power source: DC, Input voltage: 5.3 V, Power consumption (typical): 9 W. Compliance certificates: RoHS
View full details
    • Details: ATEN CS1762A. Keyboard port type: USB, Mouse port type: USB, Video port type: DVI-I. HD type: WUXGA, Maximum resolution: 1920 x 1200 pixels, Scan interval: 1,99 s. Product color: Black, Housing material: Metal. Power source: DC, Input voltage: 5.3 V, Power consumption (typical): 9 W. Compliance certificates: RoHS
    • PDF: http://objects.icecat.biz/objects/mmo_22120765_1509548349_4087_18706.pdf
    • Info: One USB console controls two DVI computers and two additional USB 2.0 devices|2-port USB 2.0 hub built in|Fully compliant with the USB 2.0 specification|Computer selection via front panel pushbuttons, hotkeys, and mouse|Audio enabled – full bass response provides a rich experience for 2.1 channel surround sound systems|Multiplatform support – Windows, Linux, Mac, and Sun|Supports widescreen resolutions|Superior video quality – 1920 x 1200|Independent switching of KVM, USB, and Audio focus|DVI digital and analog monitor support – fully compliant with the DVI specifications|HDCP compatible|Video DynaSync™ – exclusive ATEN technology optimizes display resolution and eliminates boot-up display problems|Power on detection – if one computer is powered off, the switch will automatically switch to the next powered-on computer|Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice|Complete keyboard emulation for error-free booting|Mac/Sun keyboard support and emulation*|Multilingual keyboard mapping – supports English, Japanese, and French keyboards|Auto Scan Mode for monitoring all computers|Firmware upgradable|* 1. PC keyboard combinations emulate Mac/Sun keyboards|2. Mac/Sun keyboards only work with their own computer
    • LED indicators: Yes
    • Rack mounting: No
    • Push button: Yes
    • HD type: WUXGA
    • On Screen Display (OSD): No
    • Product color: Black
    • Housing material: Metal
    • Hot keys: Yes
    • USB hub: Yes
    • Harmonized System (HS) code: 85176200
    • Operating temperature (T-T): 0 - 50 °C
    • Storage temperature (T-T): -20 - 60 °C
    • Operating relative humidity (H-H): 0 - 80%
    • Cables included: KVM
    • Manual: Yes
    • AC adapter included: Yes
    • Quick installation guide: Yes
    • Built-in display: No
    • USB connector type: USB Type-A, USB Type-B
    • Keyboard port type: USB
    • Mouse port type: USB
    • Video port type: DVI-I
    • Maximum resolution: 1920 x 1200 pixels
    • Scan interval: 1,99 s
    • Power on detection: Yes
    • DC-in jack: Yes
    • Headphone outputs: 2
    • HDCP: Yes
    • USB version: 2.0
    • Number of computers controlled: 2
    • Audio connections: Yes
    • Console ports: 3.5mm headphone, 3.5mm mic, DVI-I, USB A
    • Number of microphone inputs: 1
    • Power consumption (typical): 9 W
    • Input voltage: 5.3 V
    • Power source: DC
    • DVI-I ports quantity: 1
    • Mac operating systems supported: Yes
    • Windows operating systems supported: Yes
    • Linux operating systems supported: Yes
    • Other operating systems supported: Yes
    • Compliance certificates: RoHS
    • Weight: 25.7 oz (730 g)
    • Width: 8.27" (210 mm)
    • Height: 2.19" (55.5 mm)
    • Depth: 3.46" (88 mm)
