ATEN CS1794 KVM switch Rack mounting Black, Stainless steel
ATEN CS1794 KVM switch Rack mounting Black, Stainless steel
SKU: CS1794
Regular price
$264.54 USD
Regular price
Sale price
$264.54 USD
MSRP: $327.00
ATEN CS1794. Keyboard port type: USB, Mouse port type: USB, Video port type: HDMI. HD type: WUXGA, Maximum resolution: 1920 x 1200 pixels, Scan interval: 1,99 s. Product color: Black, Stainless steel, Rack capacity: 1U, Housing material: Metal, Plastic. Power source: DC, Input voltage: 5.3 V, Power consumption (typical): 4.8 W. Compliance certificates: RoHS
Quantity
Couldn't load pickup availability
- Details: ATEN CS1794. Keyboard port type: USB, Mouse port type: USB, Video port type: HDMI. HD type: WUXGA, Maximum resolution: 1920 x 1200 pixels, Scan interval: 1,99 s. Product color: Black, Stainless steel, Rack capacity: 1U, Housing material: Metal, Plastic. Power source: DC, Input voltage: 5.3 V, Power consumption (typical): 4.8 W. Compliance certificates: RoHS
- PDF: http://objects.icecat.biz/objects/mmo_29406594_1509434282_4647_15198.pdf
- Info: 4-port HDMI USB 2.0 KVMP™ Switch|One USB console controls four HDMI-interface computers and two additional USB devices|2-port USB 2.0 hub built in; fully compliant with the USB 2.0 specification|Independent switching of KVM, USB peripheral, and audio focus via front panel pushbuttons and hotkeys|HDMI digital monitor support - fully compliant with HDMI; also HDCP compliant|Dolby True HD and DTS HD Master Audio support|Superior video quality - supports 480i, 480p, 720p, 1080i, and 1080p(HDTV)/1920 x 1200(DVI)|Power on detection - If one of the computers is powered off, the CS1794 will automatically switch to the next powered-on computer|Supports widescreen resolutions|Multiplatform support - Windows, Linux,and Mac|Console mouse port emulation/bypass feature supports most mouse driver and multifunction mice|Video DynaSync™ - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution|Complete keyboard emulation for error-free booting|Mac keyboard support and emulation*|Auto Scan Mode for monitoring all computers and HDMI devices|Firmware Upgradable|* 1. PC keyboard combinations emulate Mac Keyboards|2. Mac keyboards only work with their own computers
- LED indicators: Yes
- Rack mounting: Yes
- Push button: Yes
- HD type: WUXGA
- On Screen Display (OSD): No
- Product color: Black, Stainless steel
- Housing material: Metal, Plastic
- Hot keys: Yes
- Harmonized System (HS) code: 85176200
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Firmware upgradeable: Yes
- Built-in display: No
- USB connector type: USB Type-A, USB Type-B
- Keyboard port type: USB
- Mouse port type: USB
- Video port type: HDMI
- Maximum resolution: 1920 x 1200 pixels
- Scan interval: 1,99 s
- Power on detection: Yes
- DC-in jack: Yes
- USB 2.0 ports quantity: 4
- HDMI ports quantity: 5
- Headphone outputs: 6
- HDCP: Yes
- Number of computers controlled: 4
- Audio connections: Yes
- Console ports: 3.5mm headphone, 3.5mm mic, HDMI, USB A
- Console USB ports quantity: 2
- Number of microphone inputs: 6
- Power consumption (typical): 4.8 W
- Input voltage: 5.3 V
- Power source: DC
- Mac operating systems supported: Yes
- Windows operating systems supported: Yes
- Linux operating systems supported: Yes
- Compliance certificates: RoHS
- Rack capacity: 1U
- Weight: 18.7 oz (530 g)
- Width: 10.3" (262.3 mm)
- Height: 1.73" (44 mm)
- Depth: 3.02" (76.8 mm)
