ATEN VE601 AV extender AV transmitter & receiver Black

ATEN VE601 AV extender AV transmitter & receiver Black

VE601

$188.80 USD
$188.80 USD
Sale Sold out

MSRP: $264.00

ATEN VE601. Type: AV transmitter & receiver, Maximum resolution: 1920 x 1200 pixels, Cable types supported: Cat5e, Cat6, Cat6a. AC input frequency: 60 Hz, Operating voltage: 5 V, Power consumption (transmitter) (max): 1.85 W. Receiver dimensions (WxDxH): 3.43 x 4.06 x 1.18" (87 x 103 x 30 mm), Receiver weight: 8.82 oz (250 g), Transmitter dimensions (WxDxH): 3.43 x 4.06 x 1.18" (87 x 103 x 30 mm)
View full details
    • Details: ATEN VE601. Type: AV transmitter & receiver, Maximum resolution: 1920 x 1200 pixels, Cable types supported: Cat5e, Cat6, Cat6a. AC input frequency: 60 Hz, Operating voltage: 5 V, Power consumption (transmitter) (max): 1.85 W. Receiver dimensions (WxDxH): 3.43 x 4.06 x 1.18" (87 x 103 x 30 mm), Receiver weight: 8.82 oz (250 g), Transmitter dimensions (WxDxH): 3.43 x 4.06 x 1.18" (87 x 103 x 30 mm)
    • Info: HDBaseT Connectivity – extends a DVI 1080p connection up to 70 meters via a single Cat 6a/ATEN 2L-2910 Cat 6 cable|DVI (3D, Deep color); HDCP 1.4 compliant|Superior video quality –1920 x 1200@35m (Cat 5e/6) / 40m (Cat 6a); 1080p@60m(Cat 5e/6) / 70m (Cat 6a)|HDBaseT Anti-Jamming – resists signal interference during video transmission using HDBaseT technology|Plug-and-play|Rack-mountable
    • Supported graphics resolutions: 1920 x 1200 (WUXGA)
    • Product color: Black
    • Type: AV transmitter & receiver
    • Bandwidth: 340 MHz
    • Impedance: 100 ?
    • Cable types supported: Cat5e, Cat6, Cat6a
    • Operating temperature (T-T): 0 - 50 °C
    • Storage temperature (T-T): -20 - 60 °C
    • Operating relative humidity (H-H): 0 - 80%
    • Manual: Yes
    • Maximum transfer distance: 2755.9" (70 m)
    • Maximum resolution: 1920 x 1200 pixels
    • DC-in jack: Yes
    • HDCP: Yes
    • DVI input ports: 1
    • DVI output ports: 1
    • AC input frequency: 60 Hz
    • Operating voltage: 5 V
    • Power consumption (receiver) (max): 4.23 W
    • Power consumption (transmitter) (max): 1.85 W
    • Material: Metal
    • Transmitter weight: 8.82 oz (250 g)
    • Receiver dimensions (WxDxH): 3.43 x 4.06 x 1.18" (87 x 103 x 30 mm)
    • Receiver weight: 8.82 oz (250 g)
    • Transmitter dimensions (WxDxH): 3.43 x 4.06 x 1.18" (87 x 103 x 30 mm)
