ATEN VE813A AV extender AV transmitter & receiver Black
ATEN VE813A AV extender AV transmitter & receiver Black
SKU: VE813A
Regular price
$888.92 USD
Regular price
Sale price
$888.92 USD
MSRP: $1,142.00
ATEN VE813A. Type: AV transmitter & receiver, Cable types supported: Cat5e, Cat6, Cat6a, Cat7, Maximum transfer distance: 3937" (100 m). Connectivity technology: Wired, USB connector type: USB Type-A, USB Type-B. Operating voltage (transmitter): 5 V, Operating voltage (receiver): 5 V, Power consumption (typical): 5.75 W. Dimensions (WxDxH): 4.64 x 7.17 x 1.13" (117.9 x 182 x 28.7 mm), Weight: 2.71 lbs (1.23 kg). Cables included: HDMI, USB
Quantity
Couldn't load pickup availability
- Details: ATEN VE813A. Type: AV transmitter & receiver, Cable types supported: Cat5e, Cat6, Cat6a, Cat7, Maximum transfer distance: 3937" (100 m). Connectivity technology: Wired, USB connector type: USB Type-A, USB Type-B. Operating voltage (transmitter): 5 V, Operating voltage (receiver): 5 V, Power consumption (typical): 5.75 W. Dimensions (WxDxH): 4.64 x 7.17 x 1.13" (117.9 x 182 x 28.7 mm), Weight: 2.71 lbs (1.23 kg). Cables included: HDMI, USB
- Info: Implements HDBaseT extension technology using only one Cat 5e/6/6a cable that connects the transmitter and receiver|Anti-jamming – high quality video transmissions via HDBaseT technology that resists signal interference|Supports Dolby True HD and DTS HD Master Audio|ExtremeUSB® – supports transparent USB 2.0 signals and true plug-and-play (no software or drivers required)|USB 2.0 Support* – connects devices such as keyboard, mouse, audio, flash drive, printer, touch panel, USB 1.1 web cameras and other USB devices which require moderate amounts of bandwidth|Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)|Works with all major operating systems: Windows®, OS X®, and Linux®|Rack-mountable|*Note: The VE813A supports a maximum combined USB transfer rate of 40 Mbps for attached USB devices
- LED indicators: Yes
- 3D: Yes
- Supported video modes: 1080p, 2160p
- Product color: Black
- Type: AV transmitter & receiver
- Bandwidth: 340 MHz
- Consumer Electronics Control (CEC) support: Yes
- Impedance: 100 ?
- Quantity per master (outer) case: 5 pc(s)
- Cable types supported: Cat5e, Cat6, Cat6a, Cat7
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Dimensions (WxDxH): 4.64 x 7.17 x 1.13" (117.9 x 182 x 28.7 mm)
- Connectivity technology: Wired
- Mounting kit: Yes
- Cables included: HDMI, USB
- AC adapter included: Yes
- Maximum transfer distance: 3937" (100 m)
- USB connector type: USB Type-A, USB Type-B
- DC-in jack: Yes
- USB ports quantity: 4
- RJ-45 input ports: 1
- RJ-45 output ports: 1
- HDCP: Yes
- USB version: 2.0
- Number of HDMI outputs: 1
- Power consumption (typical): 5.75 W
- Power consumption (receiver) (max): 13.25 W
- Operating voltage (receiver): 5 V
- Operating voltage (transmitter): 5 V
- Material: Metal
- Weight: 2.71 lbs (1.23 kg)
