ATEN VE816R AV extender AV receiver Black

ATEN VE816R AV extender AV receiver Black

VE816R

$714.28 USD
$714.28 USD
Sale Sold out

MSRP: $1,010.00

ATEN VE816R. Type: AV receiver, Maximum resolution: 4096 x 2160 pixels, Cable types supported: Cat5e, Cat6. Connectivity technology: Wired, Serial interface type: RS-232. Operating voltage: 5 V, Power consumption (typical): 9.09 W. Width: 4.92" (124.9 mm), Depth: 6.54" (166 mm), Height: 1.14" (29 mm)
View full details
    • Details: ATEN VE816R. Type: AV receiver, Maximum resolution: 4096 x 2160 pixels, Cable types supported: Cat5e, Cat6. Connectivity technology: Wired, Serial interface type: RS-232. Operating voltage: 5 V, Power consumption (typical): 9.09 W. Width: 4.92" (124.9 mm), Depth: 6.54" (166 mm), Height: 1.14" (29 mm)
    • Info: Extends HDMI, RS-232, and IR signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable|HDCP 2.2 compatible|Superior video quality:|• 4K up to 100 m|• 1080p up to 150 m|HDBaseT Long Reach Mode – activated by RS-232 commands, Long Reach Mode extends signals up to 150 m, 1080p, via a single Cat 5e/6 cable|Scaler – scales videos of different resolutions to their optimal output for display and to avoid black screen*|Video Wall – features video wall profiles that allows for custom screen layouts via an intuitive web GUI**|Seamless Switch™ – close-to-zero second switching that provides continuous video streams, real-time switching, and stable signal transmissions**|HDBaseT Anti-jamming – resists signal interference during high-quality video transmissions using HDBaseT technology|Bi-directional RS-232 channel – allows for control using serial terminals or serial devices, such as touch screens and barcode scanners|Bi-directional IR channel – IR transmission is processed one direction at a time***|Cable Quality Tester – examines the category cable quality through signal level detection from HDBaseT Matrix Switches to the VE816R.|FrameSync – prevents image tearing by synchronizing the scaler output frame rate to the input signal frame rate|Remote Firmware upgrade|Built- in 8KV / 15 KV ESD protection|Plug-and-play|Rack-mountable|Note:|1. Videos may not display within range when Seamless Switch™ or Video Wall is enabled, in which case please adjust the display settings on your device.|2. The Seamless Switch™ and video wall functionalities are available when the VE816R is used with ATEN HDBaseT Matrix. For further information, please see the compatible list below|3. Supports full-frequency IR signals from 30 KHz to 56 KHz.
    • LED indicators: Yes
    • Supported graphics resolutions: 3840 x 2160, 4096 x 2160
    • 3D: Yes
    • Supported video modes: 1080p
    • Product color: Black
    • Plug and Play: Yes
    • Type: AV receiver
    • Bandwidth: 340 MHz
    • HDBaseT certified: Yes
    • Electrostatic Discharge (ESD) protection: 15 kV
    • Impedance: 100 ?
    • Cable types supported: Cat5e, Cat6
    • Operating temperature (T-T): 0 - 40 °C
    • Storage temperature (T-T): -20 - 60 °C
    • Operating relative humidity (H-H): 0 - 80%
    • Connectivity technology: Wired
    • Manual: Yes
    • AC adapter included: Yes
    • IR receiver included: Yes
    • IR blaster included: Yes
    • Maximum transfer distance: 5905.5" (150 m)
    • Firmware upgradeable: Yes
    • Maximum resolution: 4096 x 2160 pixels
    • DC-in jack: Yes
    • Serial interface type: RS-232
    • Serial ports quantity: 1
    • RJ-45 input ports: 1
    • HDCP: Yes
    • Number of HDMI outputs: 1
    • Remote (IR) input: 1
    • Power consumption (typical): 9.09 W
    • Operating voltage: 5 V
    • External power adapter: Yes
    • Compliance certificates: RoHS
    • Material: Metal
    • Weight: 23.6 oz (670 g)
    • Width: 4.92" (124.9 mm)
    • Height: 1.14" (29 mm)
    • Depth: 6.54" (166 mm)
