ATEN VP1420 video switch HDMI/VGA
ATEN VP1420 video switch HDMI/VGA
SKU: VP1420
Regular price
$579.63 USD
Regular price
Sale price
$579.63 USD
MSRP: $733.00
ATEN VP1420. Video port type: HDMI/VGA. Material: Metal, Product color: Black, Maximum operating distance: 590.6" (15 m). Width: 6.3" (160 mm), Depth: 7.87" (200 mm), Height: 1.73" (44 mm)
Quantity
Couldn't load pickup availability
- Details: ATEN VP1420. Video port type: HDMI/VGA. Material: Metal, Product color: Black, Maximum operating distance: 590.6" (15 m). Width: 6.3" (160 mm), Depth: 7.87" (200 mm), Height: 1.73" (44 mm)
- PDF: http://objects.icecat.biz/objects/mmo_77272609_1601634824_0012_8896.pdf
- Info: Analog/Digital AV Matrix Switching|Supports multi-format 4 inputs – 3 HDMI and 1 VGA inputs|2 HDMI outputs|Audio embedding – stereo audio can be embedded into HDMI output or separated to stereo line out|Audio de-embedding – HDMI audio can be extracted to stereo line out|Auto switching – automatically detects and switches to a new source as soon as it is connected|High-definition Video with Optimum Output|Superior video quality – True 4K resolutions up to 4096 x 2160@60Hz (4:4:4) (HDMI)|Supports 4K HDR|Scaler – supports video upscaling to 4K for display A and downscaling to 1080p for display B|EDID Expert™ – automatically selects the optimum EDID settings for smooth power-up, high-quality display, and the best video resolution across connected devices|HDMI (3D, Deep Color, 4K); HDCP 2.2 compliant|Versatile, Streamlined Operation|Multiple control options – flexible control via front-panel pushbuttons, IR remote control, RS-232, and web-based GUI through Ethernet|View and control via ATEN Video Presentation Control App in a swift and agile way|Supports stand-by mode for power saving and fast waking up|Consumer Electronics Control (CEC) support|Built-in Contact in and LED out for keypad control using VPK104 Contact Closure Remote Pad
- Product color: Black
- Maximum operating distance: 590.6" (15 m)
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Video port type: HDMI/VGA
- DC-in jack: Yes
- RJ-45 input ports: 1
- HDMI ports quantity: 3
- VGA (D-Sub) ports quantity: 1
- HDCP: Yes
- RS-232 ports: 1
- HDCP version: 2.2
- Compliance certificates: RoHS
- Material: Metal
- Width: 6.3" (160 mm)
- Height: 1.73" (44 mm)
- Depth: 7.87" (200 mm)
