ATEN VP1920 video switch
ATEN VP1920 video switch
SKU: VP1920
Regular price
$617.93 USD
Regular price
Sale price
$617.93 USD
MSRP: $781.00
ATEN VP1920. Material: Metal, Product color: Black, Maximum operating distance: 590.6" (15 m). AC input voltage: 100 - 240 V, AC adapter frequency: 50 / 60 Hz, AC adapter input current: 1 A. Width: 17.2" (437.2 mm), Depth: 6.44" (163.6 mm), Height: 1.73" (44 mm). Quantity per pack: 1 pc(s)
Quantity
Couldn't load pickup availability
- Details: ATEN VP1920. Material: Metal, Product color: Black, Maximum operating distance: 590.6" (15 m). AC input voltage: 100 - 240 V, AC adapter frequency: 50 / 60 Hz, AC adapter input current: 1 A. Width: 17.2" (437.2 mm), Depth: 6.44" (163.6 mm), Height: 1.73" (44 mm). Quantity per pack: 1 pc(s)
- Info: Multi-format AV Switching with Simplicity|Supports multi-format 9 Inputs and 2 HDMI outputs:|• 3 combo inputs (HDMI/VGA, HDMI/DisplayPort, HDMI/AV/YPbPr)|• 3 HDMI inputs|• 2 HDMI outputs|VGA port supports universal analog input formats (RGBHV/RGBs/YCbCr/YPbPr)|Embed/De-embed Audio–HDMI/DisplayPort audio signals can be extracted to digital/analog audio signals; stereo / composite/component audio can be embedded to digital audio signals|High-definition Video with Optimum Output|Superior video quality up to 4096 x 2160@60Hz (4:2:0) / 4096 x 2160@30Hz (4:4:4) (HDMI/DP)|EDID Expert™ - automatically selects the optimum EDID settings for smooth power-up, high-quality display, and the best video resolution across connected devices|HDMI (3D, Deep Color, 4K); HDCP 1.4 compliant|Versatile, Streamlined Operation|Multiple control methods via front-panel pushbuttons, RS-232, OSD, and IR remote|Source preview – quickly identifies and switches to the target content|Selectable display modes (Matrix, Mirror, or PiP) for different presentation demands|Auto switching – automatically detects and switches to a new source as soon as it is connected for time-saving and convenience|Supports stand-by mode for power saving and fast waking up|Extended Flexibility for USB Peripherals|USB ports enable keyboard/mouse or touch panel control over the connected computers|Control focus for keyboard/mouse and USB peripherals can be individually switched to a designated computer source
- LED indicators: Yes
- Rack mounting: Yes
- HD type: 4K Ultra HD
- Supported graphics resolutions: 1920 x 1200 (WUXGA), 3840 x 2160, 4096 x 2160
- 3D: Yes
- Product color: Black
- Consumer Electronics Control (CEC) support: Yes
- Extended display identification data (EDID): Yes
- Harmonized System (HS) code: 85176990
- Built-in speaker(s): No
- Maximum operating distance: 590.6" (15 m)
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Heat dissipation: 60 BTU/h
- Power cord included: Yes
- Quantity per pack: 1 pc(s)
- User guide: Yes
- Handheld remote control: Yes
- Remote control type: IR
- Maximum resolution: 4096 x 2160 pixels
- HDMI ports quantity: 8
- VGA (D-Sub) ports quantity: 1
- DisplayPorts quantity: 1
- HDCP: Yes
- RS-232 ports: 1
- HDCP version: 1.4
- Audio (L/R) in: 2
- Audio (L/R) out: 2
- Composite video in: 1
- Component video (YPbPr/YCbCr) in: 1
- Number of HDMI outputs: 2
- VGA (D-Sub) output ports: 1
- HDMI in: 6
- Digital audio coaxial out: 1
- 3.5 mm (1/8-inch) in: Yes
- Power consumption (typical): 7.3 W
- AC input voltage: 100 - 240 V
- AC adapter frequency: 50 / 60 Hz
- AC adapter input current: 1 A
- Compliance certificates: RoHS
- Rack capacity: 1U
- Material: Metal
- Weight: 5.2 lbs (2.36 kg)
- Width: 17.2" (437.2 mm)
- Height: 1.73" (44 mm)
- Depth: 6.44" (163.6 mm)
