ATEN VP3520 matrix switcher Media presentation matrix switcher 46.7 W

ATEN VP3520 matrix switcher Media presentation matrix switcher 46.7 W

VP3520

$2,860.40 USD
$2,860.40 USD
Sale Sold out

MSRP: $4,114.00

ATEN VP3520. Product type: Media presentation matrix switcher, Maximum resolution (HDMI): 4096 x 2160 pixels, Supported resolutions: 4096 x 2160, 3840 x 2160, 1920 x 1080, 1920 x 1200, 1680 x 1050, 1600 x 1200, 1440 x 900, 1400 x.... Housing color: Black. Power consumption (max): 46.7 W, Power consumption (typical): 45.8 W, AC input voltage: 110 - 220 V. Width: 10.7" (272.3 mm), Depth: 17" (432.4 mm), Height: 1.73" (44 mm). Cables included: AC
View full details
    • Details: ATEN VP3520. Product type: Media presentation matrix switcher, Maximum resolution (HDMI): 4096 x 2160 pixels, Supported resolutions: 4096 x 2160, 3840 x 2160, 1920 x 1080, 1920 x 1200, 1680 x 1050, 1600 x 1200, 1440 x 900, 1400 x.... Housing color: Black. Power consumption (max): 46.7 W, Power consumption (typical): 45.8 W, AC input voltage: 110 - 220 V. Width: 10.7" (272.3 mm), Depth: 17" (432.4 mm), Height: 1.73" (44 mm). Cables included: AC
    • Info: Display Control|Auto display on / off control – supports display control through CEC, IR, RS-232, PJLink and controls projector screen through relay port|Flexible control methods – triggered by source detection or 4 function keys on front panel|Digital AV Matrix Switching|Supports multi-format 5 inputs – 3 HDMI, 2 HDBaseT|1 HDMI and 1 HDBaseT output|Audio embedding – stereo audio can be embedded into display output or separated to stereo line out and coaxial audio output|Audio de-embedding – HDMI / HDBaseT audio can be extracted to stereo line out|Built-in Audio DSP – supports microphone input with selectable 48 V Phantom Power and allows microphone input to be mixed with program audio and embedded into display output|Automatically reduces program audio when a microphone signal is detected|Auto switching – automatically detects and switches to a new source as soon as it is connected|Audio amplifier – 2 x 10 W built-in power amplifier with speaker outputs on terminal block connectors|High-Definition Video with Optimum Output|Superior video quality – True 4K resolutions up to 4096 x 2160 @ 60 Hz (4:4:4) (HDMI) / 4096 x 2160 @ 60 Hz (4:2:0) (HDBaseT)|Supports 4K HDR|4K Scaler –features a 4K video scaler to convert input resolutions to the optimum display resolutions|Seamless Switch™ –features close-to-zero second switching for continuous video streams, real-time switching, and stable signal transmissions|EDID Expert™ –automatically selects the optimum EDID settings for smooth power-up, high-quality display, and the best video resolution across the connected devices|HDMI; HDCP 2.2 compliant|Versatile, Streamlined Operation|Multiple control options – flexible control via front-panel pushbuttons, IR remote control, RS-232, and web-based GUI through Ethernet|View the device status and control it via ATEN Video Presentation Control App in a swift and agile way.|RS-232 and IR channel – allows AV device control over HDBaseT connection without additional cabling|Supports stand-by mode for power saving and fast waking up|Consumer Electronics Control (CEC) support|Extended Transmission over One Cable|Power over HDBaseT (PoH) – remote powering over existing communication cable with selectable powering device|Long-distance transmission – transmits digital AV signal, RS-232 commands, and IR control signals up to 70 m* via Cat 6/6a or ATEN 2L-2910 Cat 6 cables through HDBaseT Out port|Note: This is achieved using both the HDBaseT In and the HDBaseT Out ports on the VP3520 with each extending the transmission up to 70 m.
    • High Dynamic Range (HDR) supported: Yes
    • Product type: Media presentation matrix switcher
    • Housing color: Black
    • Maximum resolution (HDMI): 4096 x 2160 pixels
    • Extended display identification data (EDID): Yes
    • Operating temperature (T-T): 0 - 40 °C
    • Storage temperature (T-T): -20 - 60 °C
    • Operating relative humidity (H-H): 0 - 80%
    • Heat dissipation: 310 BTU/h
    • Heat dissipation (max): 314 BTU/h
    • Supported resolutions: 4096 x 2160, 3840 x 2160, 1920 x 1080, 1920 x 1200, 1680 x 1050, 1600 x 1200, 1440 x 900, 1400 x 1050, 1280 x 1024, 1280 x 800, 1024 x 768, 800 x 600, 720 x 400, 640 x 480
    • Cables included: AC
    • Manual: Yes
    • Rack mount kit: Yes
    • Handheld remote control: Yes
    • IR receiver included: Yes
    • Rubber feet: Yes
    • Package width: 13.3" (338 mm)
    • Package height: 6.1" (155 mm)
    • Package depth: 20.3" (515 mm)
    • Built-in display: No
    • RJ-45 input ports: 2
    • RJ-45 output ports: 1
    • HDCP: Yes
    • RS-232 ports: 2
    • HDCP version: 2.2
    • HDMI output ports quantity: 1
    • HDMI input ports quantity: 3
    • Analog audio output terminal ports: 1
    • Relay outputs: 2
    • Power consumption (typical): 45.8 W
    • AC input voltage: 110 - 220 V
    • Power consumption (max): 46.7 W
    • Width: 10.7" (272.3 mm)
    • Height: 1.73" (44 mm)
    • Depth: 17" (432.4 mm)
