GIGABYTE B650 AORUS ELITE AX 1.0 AMD B650 Socket AM5 ATX
GIGABYTE B650 AORUS ELITE AX 1.0 AMD B650 Socket AM5 ATX
SKU: B650 AORUS ELITE AX
Regular price
$219.99 USD
Regular price
Sale price
$219.99 USD
MSRP: $219.99
GIGABYTE B650 AORUS ELITE AX 1.0. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen™ 7. Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 6E (802.11ax), Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: AMD
Quantity
Couldn't load pickup availability
- Details: GIGABYTE B650 AORUS ELITE AX 1.0. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen™ 7. Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 6E (802.11ax), Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: AMD
- Info: AMD Socket AM5?Supports AMD Ryzen™ 7000 Series Processors|Unparalleled Performance?Twin 14*+2+1 Phases Digital VRM Solution|Dual Channel DDR5?4*SMD DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support|Next Generation Storage?1*PCIe 5.0 x4 and 2*PCIe 4.0 x4 M.2 Connectors|Fully Covered Heatpipe & M.2 Thermal Guard?To Ensure VRM Power Stability & 25110 PCIe 5.0 M.2 SSD Performance|EZ-Latch?PCIe x16 Slot & M.2 Connectors with Quick Release & Screwless Design|Fast Networks?2.5GbE LAN & Wi-Fi 6E 802.11ax|Extended Connectivity?DP, HDMI, Rear USB-C® 10Gb/s, Front USB-C® 20Gb/s|Smart Fan 6?Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP|Q-Flash Plus?Update BIOS Without Installing the CPU, Memory and Graphics Card
- BIOS type: UEFI AMI
- BIOS memory size: 256 Mbit
- System Management BIOS (SMBIOS) version: 2.7
- Clear CMOS jumper: Yes
- Desktop Management Interface (DMI) version: 2.7
- Component for: PC
- PCI Express x16 slots: 3
- Number of M.2 (M) slots: 3
- Product color: Black
- Motherboard form factor: ATX
- Motherboard chipset family: AMD
- PC health monitoring: Fan, Temperature, Voltage
- On-board graphics card: No
- USB 2.0 connectors: 2
- ATX Power connector (24-pin): Yes
- Number of chassis fan connectors: 4
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Front panel connector: Yes
- Front panel audio connector: Yes
- Thunderbolt headers: 2
- 12V power connector: Yes
- RGB LED pin header: Yes
- Maximum internal memory: 128 GB
- Memory channels: Dual-channel
- Supported memory types: DDR5-SDRAM
- ECC ?ompatibility: ECC & Non-ECC
- Supported memory clock speeds: 4400,4800,5200,5600,6000,6200,6400,6600 MHz
- Memory slots type: DIMM
- Number of memory slots: 4
- Unbuffered memory: Yes
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
- WLAN controller model: AMD RZ616
- Bluetooth: Yes
- Bluetooth version: 5.2
- ACPI version: 5.0
- Audio output channels: 7.1 channels
- Cables included: SATA
- Motherboard chipset: AMD B650
- Compatible processor series: AMD Ryzen™ 7
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- HDMI ports quantity: 1
- HDMI version: 2.1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- DisplayPorts quantity: 1
- HDCP: Yes
- DisplayPort version: 1.4
- Number of SATA III connectors: 4
- Processor manufacturer: AMD
- Processor socket: Socket AM5
- Maximum number of SMP processors: 1
- WiFi-AP antenna jack: 2
- Drivers included: Yes
- RAID levels: 0, 1, 5, 10
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Width: 12" (305 mm)
- Depth: 9.61" (244 mm)
