GIGABYTE Z890I AORUS ULTRA motherboard Intel Z890 LGA 1851 (Socket V1) mini ITX
GIGABYTE Z890I AORUS ULTRA motherboard Intel Z890 LGA 1851 (Socket V1) mini ITX
SKU: Z890I AORUS ULTRA
Regular price
$349.99 USD
Regular price
Sale price
$349.99 USD
MSRP: $349.99
GIGABYTE Z890I AORUS ULTRA. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 7 (802.11be), Wi-Fi standards: Wi-Fi 7 (802.11be). Component for: PC, Motherboard form factor: mini ITX, Motherboard chipset family: Intel
Quantity
Couldn't load pickup availability
- Details: GIGABYTE Z890I AORUS ULTRA. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 7 (802.11be), Wi-Fi standards: Wi-Fi 7 (802.11be). Component for: PC, Motherboard form factor: mini ITX, Motherboard chipset family: Intel
- Info: Digital 8+1+2+1 Phases 105A SPS VRM with Tantalum Polymer Capacitor|Reinforced PCIe UD Slot X PCIe 5.0 with PCIe EZ-Latch Plus Design|PCIe M.2 design (Up to 2280) with M.2 EZ-Latch Plus & Thermal Guard|Fully Covered MOSFET Heatsinks with heatpipe/M.2 EZ-Latch Click Design|Intel 2x2 Wi-Fi 7 BE202 with WIFI EZ-Plug Design|2.5GbE LAN, THUNDERBOLT 4 Type-C, USB 3.2 Gen2 Type-C®
- Clear CMOS button: Yes
- BIOS type: UEFI AMI
- BIOS memory size: 256 Mbit
- System Management BIOS (SMBIOS) version: 2.7
- Clear CMOS jumper: Yes
- Desktop Management Interface (DMI) version: 2.7
- Battery technology: Lithium-Manganese Dioxide (LiMnO2)
- Number of battery cells: 1
- Lithium weight per battery: 0.00247 oz (0.0700 g)
- Component for: PC
- PCI Express x16 slots: 1
- Number of M.2 (M) slots: 2
- Product color: Black
- Motherboard form factor: mini ITX
- Motherboard chipset family: Intel
- PC health monitoring: Fan, Temperature, Voltage
- USB 2.0 connectors: 1
- ATX Power connector (24-pin): Yes
- TPM connector: Yes
- EPS power connector (8-pin): Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- 12V power connector: Yes
- RGB LED pin header: Yes
- Country of origin: China
- Warranty period: 3 year(s)
- Quantity per shipping (inner) case: 1 pc(s)
- Maximum internal memory: 256 GB
- Memory channels: Dual-channel
- Supported memory types: DDR5-SDRAM
- ECC ?ompatibility: Non-ECC
- Supported memory clock speeds: 5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,7900,7950,8000,8200,8266,8400,8600 MHz
- Memory slots type: DIMM
- Number of memory slots: 2
- Supported memory module capacities: 1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 24GB, 32GB, 40GB, 48GB, 64GB
- Supported memory clock speed (max): 8800 MHz
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Wi-Fi standards: Wi-Fi 7 (802.11be)
- WLAN controller model: Intel Wi-Fi 7 BE202
- Bluetooth: Yes
- Bluetooth version: 5.4
- ACPI version: 5.0
- Bundled software: Norton® Internet Security (OEM version)
- LAN bandwidth management software
- Audio output channels: 7.1 channels
- Batteries included: Yes
- Package width: 10.4" (265 mm)
- Package height: 3.82" (97 mm)
- Package depth: 9.25" (235 mm)
- Package weight: 3.62 lbs (1.64 kg)
- Motherboard chipset: Intel Z890
- Compatible processor series: Intel Core Ultra (Series 2)
- Supported processor sockets: LGA 1851
- DirectX version: 12.0
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- HDMI ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- DisplayPorts quantity: 1
- Microphone in: Yes
- S/PDIF out port: Yes
- Total number of SATA connectors: 2
- Number of SATA III connectors: 2
- Thunderbolt ports quantity: 1
- Battery type: CR2032
- Processor manufacturer: Intel
- Processor socket: LGA 1851 (Socket V1)
- Maximum internal memory supported by processor: 256 GB
- Number of storage drives supported: 2
- RAID levels: 0, 1, 5, 10
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
- Number of HDDs supported: 4
- Windows operating systems supported: Windows 11 x64
- Weight: 3.13 lbs (1.42 kg)
- Width: 6.69" (170 mm)
- Height: 1.38" (35 mm)
- Depth: 6.69" (170 mm)
- Battery weight: 0.106 oz (3 g)
