GIGABYTE Z890M GAMING X motherboard Intel Z890 LGA 1851 (Socket V1) micro ATX

GIGABYTE Z890M GAMING X motherboard Intel Z890 LGA 1851 (Socket V1) micro ATX

Z890M GAMING X

$179.99 USD
$179.99 USD
Sale Sold out

MSRP: $179.99

GIGABYTE Z890M GAMING X. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet. Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: Intel
View full details
    • Details: GIGABYTE Z890M GAMING X. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet. Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: Intel
    • Info: Digital 8+1+2+1 Phases 50A PowerPak VRM with Solid Capacitor|Reinforced PCIe UD Slot PCIe 5.0 with PCIe EZ-Latch Design|PCIe M.2 design (Up to 2580) with Thermal Guard|Fully Covered MOSFET Heatsinks|2.5GbE LAN, USB 3.2 Gen1 Type-C®
    • Clear CMOS button: Yes
    • BIOS type: UEFI AMI
    • BIOS memory size: 256 Mbit
    • System Management BIOS (SMBIOS) version: 2.7
    • Clear CMOS jumper: Yes
    • Desktop Management Interface (DMI) version: 2.7
    • Battery technology: Lithium-Manganese Dioxide (LiMnO2)
    • Number of battery cells: 1
    • Lithium weight per battery: 0.00247 oz (0.0700 g)
    • Component for: PC
    • PCI Express x16 slots: 1
    • Number of M.2 (M) slots: 3
    • Product color: Black
    • Motherboard form factor: micro ATX
    • Motherboard chipset family: Intel
    • PC health monitoring: Fan, Temperature, Voltage
    • USB 2.0 connectors: 2
    • ATX Power connector (24-pin): Yes
    • TPM connector: Yes
    • EPS power connector (8-pin): Yes
    • USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
    • USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
    • 12V power connector: Yes
    • RGB LED pin header: Yes
    • Country of origin: China
    • Warranty period: 3 year(s)
    • Quantity per shipping (inner) case: 1 pc(s)
    • Maximum internal memory: 256 GB
    • Memory channels: Dual-channel
    • Supported memory types: DDR5-SDRAM
    • ECC ?ompatibility: Non-ECC
    • Supported memory clock speeds: 5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,7900,7950,8000,8200,8266,8400,8600 MHz
    • Memory slots type: DIMM
    • Number of memory slots: 4
    • Supported memory module capacities: 1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 24GB, 32GB, 40GB, 48GB, 64GB
    • Supported memory clock speed (max): 8800 MHz
    • Ethernet LAN: Yes
    • Wi-Fi: No
    • Ethernet interface type: 2.5 Gigabit Ethernet
    • ACPI version: 5.0
    • Bundled software: Norton® Internet Security (OEM version)
    • LAN bandwidth management software
    • Audio output channels: 7.1 channels
    • Batteries included: Yes
    • Package width: 10.6" (270 mm)
    • Package height: 2.68" (68 mm)
    • Package depth: 10.6" (268 mm)
    • Package weight: 2.69 lbs (1.22 kg)
    • Motherboard chipset: Intel Z890
    • Compatible processor series: Intel Core Ultra (Series 2)
    • Supported processor sockets: LGA 1851
    • DirectX version: 12.0
    • Ethernet LAN (RJ-45) ports: 1
    • USB 2.0 ports quantity: 2
    • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
    • HDMI ports quantity: 1
    • DisplayPorts quantity: 2
    • Microphone in: Yes
    • S/PDIF out port: Yes
    • Total number of SATA connectors: 4
    • Number of SATA III connectors: 4
    • Battery type: CR2032
    • Processor manufacturer: Intel
    • Processor socket: LGA 1851 (Socket V1)
    • Maximum internal memory supported by processor: 256 GB
    • Number of storage drives supported: 4
    • RAID levels: 0, 1, 5, 10
    • Supported storage drive types: HDD & SSD
    • Supported storage drive interfaces: M.2, SATA III
    • RAID support: Yes
    • Number of HDDs supported: 7
    • Windows operating systems supported: Windows 10 x64, Windows 11 x64
    • Weight: 2.43 lbs (1.1 kg)
    • Width: 9.61" (244 mm)
    • Height: 1.38" (35 mm)
    • Depth: 9.61" (244 mm)
    • Battery weight: 0.106 oz (3 g)
