- Details: APC MGE Galaxy 3500. Output power capacity: 15 kVA, Output power: 12000 W, Input operation voltage (min): 160 V. AC outlets quantity: 3 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA). Form factor: Tower, Display type: LCD. Certification: FCC, CSA, ISO, IEC, EMC, EMI, RFI, CE
- Battery technology: Sealed Lead Acid (VRLA)
- Certification: FCC, CSA, ISO, IEC, EMC, EMI, RFI, CE
- Form factor: Tower
- Safety: cUL, UL
- Display type: LCD
- Power protection features: Short circuit
- Input operation voltage (min): 160 V
- Input operation voltage (max): 240 V
- Input frequency: 40/70 Hz
- Efficiency: 93%
- Power factor: 0.5
- Output power capacity: 15 kVA
- Surge protection: Yes
- Input current Total Harmonic Distortion (THD): 5%
- Output voltage Total Harmonic Distortion (THD): 2%
- Overload protection: Yes
- Operating temperature (T-T): 32 - 104 °F
- Storage temperature (T-T): -15 - 45 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Operating altitude: 0 - 39366.1" (0 - 999.9 m)
- Non-operating altitude: 0 - 590551.2" (0 - 15000 m)
- Nominal output voltage: 208 V
- Nominal input voltage: 208 V
- Input connection type: 3PH + N + G
- Package dimensions (WxDxH): 25.6 x 41.8 x 64.7" (650 x 1062 x 1643 mm)
- Output voltage note: 208/220V
- Package weight: 983 lbs (445.9 kg)
- Noise level: 51.3 dB
- AC outlets quantity: 3 AC outlet(s)
- RS-232 ports: 1
- Output power: 12000 W
- Weight: 914.9 lbs (415 kg)
- Width: 20.6" (523 mm)
- Height: 58.7" (1491 mm)
- Depth: 33" (838 mm)
